Complex Fiber Structures
About the company
Mission
Complex Fiber Structures GmbH specializes in the development of engineering software as well as consulting and services for the implementation of variable-axial fiber-plastic composite technologies and designs. We have been offering innovative solutions and products for industry and research since 2013.
Vision
Our vision is to take lightweight structural engineering with fiber-plastic composites to a new, sustainable level. The aim is to reduce the use of materials to a minimum while maximizing component performance through the use of our software products.
Services
Development of software solutions
Complex Fiber Structures GmbH develops software solutions for the design and manufacture of variable-axial composites.
These highly optimized complex composite structures are used, among other things, in extreme lightweight construction and can preferably be manufactured using Tailored Fiber Placement (TFP) technology.
Consulting and services
We are happy to support you in the development of your sophisticated composite component with comprehensive consulting services. These range from structural design, for example with the aid of simulation models based on your variable-axial TFP deposit pattern, to the creation of optimized machine data for automated preform production.
Products
Distribution by:
🇯🇵 Japan
Distribution by:
🇯🇵 Japan
EDOstructure
With EDOstructure you can digitally model the development process of your TFP component.
EDOpath
EDOpath is the first CAM software specifically designed for Tailored Fiber Placement.
WIREpath
With WIREpath you can quickly and easily create stitch pattern data for your wire laying applications.
Digital workflow
EDOstructure
Import and flattening of meshed component model
EDOstructure
Design of fiber patterns (automated / manual)
EDOstructure
Export of model for FE-analysis and tool geometry
EDOstructure
CAD fiber pattern export for preform manufacturing
EDOpath
Optimization of imported fiber patterns and stitch distribution
EDOpath
Part thickness analysis and export of CAM data
EDOstructure
Import and flattening of meshed component model
EDOstructure
EDOstructure
Design of fiber patterns
(automated / manual)
EDOstructure
Export of model for FE-analysis and tool geometry
EDOstructure
EDOstructure
CAD fiber pattern export for preform manufacturing
EDOpath
Optimization of imported fiber patterns and stitch distribution
EDOpath
EDOpath
Part thickness analysis and export of CAM data
Our clients
